SRFS Teleinfra

0.8mm Male to 1.0mm Female Adaptor

0.8mm Male to 1.0mm Female Adaptor

Electrical & Mechanical Specifications

Impedance

50 Ohm

Frequency Range

DC-110 GHz

VSWR

1.35 max

Operating Temp

-55 to +85

Connector Body

Passivated stainless steel

Center Contact

Gold plated beryllium copper

Insulator

PEIs

View full details
