2-Way Power Splitter 698-4000MHz Square Type

2-Way Power Splitter 698-4000MHz Square Type

Electrical & Mechanical Specifications



Freq (MHz)

698-4000

Input Port Number

1

Output Port Number

2

Split Loss(dB)

3.0

IL (dB)

≤0.4

VSWR

≤1.25

3rd PIM (dBc)

≤-150dBc@2*43dBm

Average Power(W)

300

Impedance

50 ohm

Connector

N-Female

Color

Weight Black or Customized

Temp(deg)

-35~+65

Application

Indoor & Outdoor IP65

Relative Humidity

5%-95%

              Dimensions(mm)

           243.2*60.4*25 (Connectors Included)
