N-F 4 In 4 Out Hybrid Combiner 698-4000MHz
N-F 4 In 4 Out Hybrid Combiner 698-4000MHz
Couldn't load pickup availability
Electrical and Mechanical Specifications
| Frequency range | 698MHz -4000MHz |
| Insert loss | ≤6dB |
| VSWR | ≤1.25 |
| Isolation | ≥23dB |
| PIM3 | ≤-150dBc@2×43dBm |
| Power | 500W |
| Impedance | 50Ω |
| Connector | N-F |
| Degree of protection | IP65 |
| Appearance | Black paint |
| Relative humidity | 0 to 95% |
| Operating Temperature (°C) | -20° C to +70° C |
